Turnigy Aerodrive SK3 - 6374-149KV Brushless Outrunner Motor
Once again we instructed our engineers to develop a motor that would not only rival but surpass the quality of the leading motors on the market today using the best quality magnets, bearings, and materials available.
The result is an outstanding series of motors that are efficient, strong, and robust enough for the most discerning modeler.
All of the SK3 series use quality double-shielded bearings, sintered neodymium magnets (the strongest type of permanent magnet commercially available), and a string wound stator to ensure accurate and consistent winding each and every time.
Performance Data (12S):
21x12: 2332W, 55A, 9833g static thrust
21x13.5: 2545W, 60A, 10810g static thrust
22x12: 2675W, 64A, 10891g static thrust
Turnigy SK3 brushless motors are yet another step forward in motor evolution.
Once again we instructed our engineers to develop a motor that would not only rival but surpass the quality of the leading motors on the market today using the best quality magnets, bearings, and materials available.
The result is an outstanding series of motors that are efficient, strong, and robust enough for the most discerning modeler.
All of the SK3 series use quality double-shielded bearings, sintered neodymium magnets (the strongest type of permanent magnet commercially available), and a string wound stator to ensure accurate and consistent winding each and every time.
The Turnigy SK3 motors are suited to modelers who are seeking a top-quality brushless motor without compromise.
Features:
• Double shielded bearings
• Sintered neodymium magnets
• String wound stator
• High-quality finish
• Super-smooth operation
Specs:
Turns: 18T
Voltage: 12S Lipoly
RPM/V: 149KV
Internal resistance: 0.021 Ohm
Max Loading: 70A
Max Power: 27000W
Shaft Dia: 8.0mm
Bolt holes: 32mm
Bolt thread: M4
Weight: 840g
Motor Plug: 4.0mm Bullet Connector
Included:
Motor
Mount & screws
Prop adapter
Performance Data (12S):
21x12: 2332W, 55A, 9833g static thrust
21x13.5: 2545W, 60A, 10810g static thrust
22x12: 2675W, 64A, 10891g static thrust
| Kv(rpm/v) | $149.00 |
|---|---|
| Max Current (Motor) (A) | $70.00 |
| Resistance (mh) | $21.00 |
| Max Voltage (V) | $44.00 |
| Power (W) | $2,250.00 |
| Shaft A(mm) | $8.00 |
| Length B (mm) | $86.00 |
| Can Diameter C(mm) | $63.00 |
| Can Length D(mm) | $74.00 |
| Total Length E(mm) | $113.00 |
