Motori di Aeroplani

B36-60-06L Brushless Inrunner 4000kv

KV: 4000
Max corrente: 100A
Potenza massima: 1300W
Idle corrente: 6.2A
Resistenza: 0.005Ω
Albero: Φ5.0mm
Peso: 260g
ESC consigliato: 120A
Conteggio delle cellule: 2-3SLipo
Spaziatura fori dei bulloni: 25mm
Filo Bolt: M3,0 * 4
Collegamento Oro: Φ4.0

Turnigy EasyMatch Park250 Series - albero di ricambio

Spec.
Lunghezza albero: 34 millimetri
Diametro albero: 2mm

Turnigy EasyMatch G110 Series - albero di ricambio

Spec.
Lunghezza albero: 78 millimetri
Diametro albero: 13mm

Progettato come un 50 a 80cc sostituzione del motore a gas, questo motore è un bullone diretto per 17 ~ 30lb Sport, Scala e gli aerei in 3D.
Un motore perfetto dimensioni per il 3D volo fino a £ 20.
Il motore è molto ben costruito con i supporti forti, campana estremità e una concentrici doppi cuscinetti nella parte posteriore per supportare grandi eliche e può rotanti, in particolare durante il duro volo 3D.

Questo motore è molto ben progettato e di alta qualità.
La fabbrica può produrre solo un numero limitato di questi motori al mese a causa della maggiore tempo di bilanciamento e la lavorazione di un oggetto così grande.


Spec.
Modello: 80-80-10
Resistenza: 0.011ohm
ESC richiesto: 200A
Tensione in ingresso: 30 ~ 50V
Kv: 160 giri / V
Peso: 1545g
Albero: 8mm
Non Corrente di carico: 6.0A a 20V
Dimensioni: 152x133x81mm (tra cui il Monte)
Equivalente: 50-80cc Gas Engine

Turnigy SK3 motori sono il prossimo salto di qualità del motore e del design. Abbiamo incaricato i nostri ingegneri per procurarsi i componenti migliori e sviluppare un motore che avrebbe superato la qualità di molti produttori leader a motore sul mercato oggi.

Il risultato è un motore di qualità ad alta efficienza con cuscinetti a doppia schermatura, magneti al neodimio sinterizzato e uno statore stringa ferita garantendo un robusto, preciso e costante avvolgimento ogni volta.

I motori Turnigy SK3 sono adatti per modellisti che sono alla ricerca di un motore brushless qualità senza compromessi.

Specifiche:
Attiva: 8T
Kv 1050
Resistenza interna: 0.016 Ohm
Voltaggio: 11.1 ~ 14.8V (3 ~ 4S LiPoly)
Max carico: 50A max
Potenza: 820W
Albero diametro: 5,0 millimetri
Bulloni di montaggio: 25mm x M3
Connettori: Richiamo 3,5 millimetri
Peso: 176g

Turnigy SK3 motori sono il prossimo salto di qualità del motore e del design. Abbiamo incaricato i tecnici di procurarsi i migliori qualità magneti, cuscinetti e materiali a loro disposizione e sviluppare un motore che non solo rivale, ma superare oggi la qualità di molti motori principali produttori sul mercato. Il risultato è un efficiente, ad alta motore calibro usando qualità doppi cuscinetti schermati, magneti al neodimio sinterizzato e uno statore stringa ferita garantire un accurato e costante avvolgimento ogni volta. I motori Turnigy SK3 sono adatti per modellisti che sono alla ricerca di un motore brushless qualità senza compromessi. Specs.Turns: 14TVoltage: 10 ~ 12S LipolyRPM / V: resistenza 192kvInternal: 0.016 OhmMax Caricamento: 80AMax Potenza: 2750WShaft Dia: fori 8.0mmBolt: filo 32mmBolt: M4Weight: 858gMotor spina: 4,0 millimetri proiettile connettore

26 millimetri Diametro Motor Mount - Stile morsetto per Inrunner motore

Spec.
Diametro: 26mm (Fits 380 Dimensioni Inrunner)
Lunghezza: 48,5 millimetri
Peso: 14g

Combinato con un 10x6 e-prop questo motore può spingere fuori sopra 1000g in spinta su un lipo di configurazione 3S1P.
Buon per foamies più grandi o parkflyers dove circa è richiesta 150W.

Spec.
Kv: 1050rpm / v
Corrente di funzionamento: 6A ~ 16A
Corrente di picco: 19A
Peso: 56g
Dimensioni: 27,6 x 32mm
Dimensione stelo: 3,175 millimetri

Il kit include gli accessori pieni, tra cui connettori proiettile d'oro, risparmiatore puntello, il montaggio, gli anelli di gomma di ricambio, shrink tubo e viti.

performance Data
Tensione Corrente Prop spinta
11.1V 8.6A 8040 538g
11.1V 13.7A 9050 810g
11.1V 16.7A 1060 650g

3730-1000kv Turnigy aria motore brushless

Specifiche tecniche:
Dimensioni: 37 mm x 30 millimetri
Peso: 112g Inc 4 millimetri in oro connettore (130g inc tutti i raccordi)
Kv: 1000rpm / V
Voltaggio: 11.1V ~ 14.8V (3s ~ 4s)
Potenza massima: 580W
Max corrente: 42A
Corrente a vuoto: 1.6A
Diametro del pozzo: 4mm
Spinta: 1700g
ESC: 60A

Specifiche.
RPM / V: 1350Kv
Cell Count: 2s ~ 3s Lipoly
Di corrente massimo: 10A
Max Watt: 120W
Corrente a vuoto: 0.3A / 7.4V
Dimensioni: Φ28mm × 16 millimetri
Albero: 3mm
Peso: 26g
Spinta max: 245g

DYS D2225/13 2000KV Brushless Outrunner Motor

Specs:
Battery: 2~3 Cell /7.4~11.1V
RPM: 2000kv
Max current: 11A
Max power: 122W
Internal resistance: 0.143 ohm
Weight: 32g (including connectors)
Diameter of shaft: 3.17mm
Dimensions: 22x25mm
Prop size: 6x4/6x5

DYS D2225/19 1350KV Brushless Outrunner Motor

Specs:
Battery: 2~3 Cell /7.4~11.1V
RPM: 1350kv
Max current: 8.2A
Max power: 105W
Internal resistance: 0.203 ohm
Weight: 32g (including connectors)
Diameter of shaft: 3.17mm
Dimensions: 22x25mm
Prop size: 6x5/7x3

PROPDRIVE v2 motors are designed to perform right out of the box with tight windings, smooth bearings, correctly rated magnets, precision cut stator, and balanced rotors.

We design and build the PROPDRIVE v2 motors in-house, allowing us to control every aspect of production. We control the entire production line from material sourcing to machining, balancing, and final assembly. PROPDRIVE motors can be trusted to provide years of reliable service at a price every modeler can afford.

Performance Data (5S):
15x6: 796W, 45A, 3338g static thrust
15x8: 970W, 56A, 4151g static thrust
16x7: 1053W, 60A, 4259g static thrust

Performance Data (6S):
13x6.5: 896W, 42A, 3567g static thrust
13x8: 1042W, 50A, 4214g static thrust
14x7: 1170W, 56A, 4439g static thrust

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The heatsink can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and oversized bearings are used for durability. The stator has super thin (0.2mm) laminations, and the rotor is then precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and oversized bearings are used for durability. The stator has super thin (0.2mm) laminations, and the rotor is then precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 2822-1740KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 2~3S, and a range of props from 4~6". This motor on test with a 3S battery gave 100W of power at 9.5A, making it a great motor for small models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and oversized bearings are used for durability. The stator has super thin (0.2mm) laminations, and the rotor is then precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 2830-1130KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 2~3S, and a range of props from 8~12". This motor on test with a 3S battery gave 200W of power at 19A, making it a great motor for small to medium size models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and oversized bearings are used for durability. The stator has super thin (0.2mm) laminations, and the rotor is then precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 3536-1050KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 2~4S, and on test with a 4S battery gave 650W of power at 49A, making it a great motor for medium-size models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and oversized bearings are used for durability. The stator has super thin (0.2mm) laminations, and the rotor is then precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 3542-1250KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 3~4S, and on test with a 4S battery gave 707 watts of power at 52A, making it a great motor for medium-size models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The heatsink can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and oversized bearings are used for durability. The stator has super thin (0.2mm) laminations, and the rotor is then precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 3548-840KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 3~4S, and on test with a 4S battery gave 685 watts of power at 50A, making it a great motor for medium-size models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The heatsink can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and double-shielded oversized bearings are used for durability. The motor includes sintered neodymium magnets, the stator has super thin (0.2mm) laminations, and the rotor is precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 5045-500KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 5~7S, and on test with a 6S battery gave 1217 watts of power at 58A, making it a great motor for the larger models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The heatsink can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and double-shielded oversized bearings are used for durability. The motor includes sintered neodymium magnets, the stator has super thin (0.2mm) laminations, and the rotor is precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 5065-236KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries up to 10S, on test with a 10S battery it produced an incredible 2000 watts of power at 57A, making it a great motor for the larger models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The heatsink can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and double-shielded oversized bearings are used for durability. The motor includes sintered neodymium magnets, the stator has super thin (0.2mm) laminations, and the rotor is precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 5065-275KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 6 to 10S, on test with a 10S battery it produced an incredible 2300 watts of power at 65A, making it a great motor for the larger models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The heatsink can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and double-shielded oversized bearings are used for durability. The motor includes sintered neodymium magnets, the stator has super thin (0.2mm) laminations, and the rotor is precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 2826-1000KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 2 to 3S, on test with a 3S battery it produced 173 watts of power at 16A, making it a great motor for the smaller models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

The Rocket Surpass range of brushless motors is precision-made using the latest manufacturing processes. The heatsink can is CNC machined from a solid billet of 6061 T6 aluminum, high-purity copper is used for the windings for improved efficiency, and double-shielded oversized bearings are used for durability. The motor includes sintered neodymium magnets, the stator has super thin (0.2mm) laminations, and the rotor is precision balanced for reliability, and ultra-smooth running at maximum RPMs.

The Rocket Surpass 3536-1300KV motor suits sport, scale, and 3D-type models. This robust motor suits LiPo batteries from 3 to 4S, on test with a 4S battery it produced 526 watts of power at 38A, making it a great motor for the medium size models. The motor is supplied with a machined prop adapter, complete with mounting bolts, allowing it to be mounted either way round.

Stile Motore Campana Turnigy L2210-1650

Spec.
Kv: 1650 rpm / v
Voltaggio: 7.4 ~ 11.1v (2 ~ 3s)
Corrente a vuoto: 1.3A
Max corrente: 22A
Potenza massima: 250W
Albero Formato: 3mm
Lunghezza del pozzo: 28mm
Dimensioni: 28mm x 17mm
Spinta: 520g
Peso: 50g

Aggiorna il tuo modello di motore a gas dimensioni 100cc con motore outrunner Turnigy Rotomax 100cc Brushless. Questo motore fornirà energia pulita ed efficiente per il vostro aereo su larga scala senza il disordine e il fastidio di carburante.

Se combinato con una batteria 12s Lipoly, 27x12 Elica e un 250Amp ESC il Rotomax motore fornirà incisivo, potenza reattiva che solo una configurazione elettrica in grado di fornire.

Questo motore è specificamente adatto per la fibra di carbonio e le eliche in legno e dispone di un IC stile 6 disegno del foro del bullone. L'albero è stato anche sfruttato per soddisfare un bullone 5 mm a fare il montaggio di un filatore di vostra scelta facile.

Spec.
Batteria: 12 cellule / 44.4V
RPM: 167kv
Max corrente: 170A
Watts: 7992w
Corrente a vuoto: 44V / 4.5A
Resistenza interna: 0.021 Ohm
Peso: 2074g
Conte Palo: 24
Diametro del pozzo: 10mm
Suggerita ESC: 250A 12S compatibile
Suggerita Prop: 27x12

Aggiorna il tuo modello di motore a gas da 50cc con il motore outrunner senza spazzole Turnigy RotoMax da 50cc. Questo motore fornirà energia pulita ed efficiente per il tuo aereo su larga scala senza il disordine e il fastidio del carburante.

The Dr. Mad Thrust EDF series are pre-assembled and dynamically balanced making them easy to fit, with no unit assembly required. As well as high power, these fans have excellent cooling and run so smoothly, the sound is amazing. There is also no housing distortion, unlike plastic fans. This high quality, powerful fan is a great way to upgrade your 70mm EDF jet to a speeding missile in around an hour!
