Corona 919MG Digital Metal Gear Servo 1.7kg / 0.06sec / 12g
€ 8,37
Out of stock
SKU
DS919MG
Corona 919MG Metal Gear Servo 1.7kg / 0.06sec / 12,5 g
Spec.
Spec.
Model: DS919MG
Operating Voltage: 4.8V / 6.0V
Werkende stroom: 200mA / 240mA
Operating Speed: 0.07sec.60º / 0.06sec.60º
Stall Koppel: 1.5kg.cm /1.7kg.cm
Grootte: 22.5X11.5X24.6mm (0,88 "x0.45" x0.96 ")
Gewicht: 12,5 g
Operating Voltage: 4.8V / 6.0V
Werkende stroom: 200mA / 240mA
Operating Speed: 0.07sec.60º / 0.06sec.60º
Stall Koppel: 1.5kg.cm /1.7kg.cm
Grootte: 22.5X11.5X24.6mm (0,88 "x0.45" x0.96 ")
Gewicht: 12,5 g
Dead Band: ≤3uSec
Operating Travel: 40º / ene kant pulse reizen 400US
Potentiometer: 2 slider / Direct Drive
Kogellager: MR85
Gear: Metal
Connector draad: 215mm
Bedrijfstemperatuurbereik: -20J + 60J
Operating Travel: 40º / ene kant pulse reizen 400US
Potentiometer: 2 slider / Direct Drive
Kogellager: MR85
Gear: Metal
Connector draad: 215mm
Bedrijfstemperatuurbereik: -20J + 60J
Corona 919MG Metal Gear Servo 1.7kg / 0.06sec / 12,5 g
Spec.
Spec.
Model: DS919MG
Operating Voltage: 4.8V / 6.0V
Werkende stroom: 200mA / 240mA
Operating Speed: 0.07sec.60º / 0.06sec.60º
Stall Koppel: 1.5kg.cm /1.7kg.cm
Grootte: 22.5X11.5X24.6mm (0,88 "x0.45" x0.96 ")
Gewicht: 12,5 g
Operating Voltage: 4.8V / 6.0V
Werkende stroom: 200mA / 240mA
Operating Speed: 0.07sec.60º / 0.06sec.60º
Stall Koppel: 1.5kg.cm /1.7kg.cm
Grootte: 22.5X11.5X24.6mm (0,88 "x0.45" x0.96 ")
Gewicht: 12,5 g
Dead Band: ≤3uSec
Operating Travel: 40º / ene kant pulse reizen 400US
Potentiometer: 2 slider / Direct Drive
Kogellager: MR85
Gear: Metal
Connector draad: 215mm
Bedrijfstemperatuurbereik: -20J + 60J
Operating Travel: 40º / ene kant pulse reizen 400US
Potentiometer: 2 slider / Direct Drive
Kogellager: MR85
Gear: Metal
Connector draad: 215mm
Bedrijfstemperatuurbereik: -20J + 60J
| Servo Torque ( kg) ( min . 0,01 kg ) | € 1,57 |
|---|---|
| Servo Snelheid ( Sec / 60deg ) | € 0,06 |
| Servo A ( mm ) | € 28,55 |
| Servo B ( mm ) | € 21,19 |
| Servo C ( mm ) | € 26,71 |
| Servo D ( mm ) | € 11,05 |
| Servo E ( mm ) | € 29,48 |
| Servo F ( mm ) | € 18,42 |
| Item Returns | This item can be returned |
