Specs:
Type: Turnigy TrackStar Stock 540 Sensored Brushless Motor
Scale: 1/10th (stock class)
Poles: 2
Turns: 21.5
KV: 2350KV
Sensored: Yes (Standard 6-pin lead)
Sensor Lead: Included
Input Voltage: 7.4~11.1V (2~3S)
Max Current: 28A
Max Watts: 100
Resistance: 0.0558 ODM
Motor Diameter: 35.8mm
Motor Length: 52mm
Shaft Diameter: 3.175mm
Shaft Length: 13.9mm
Mounting Screw Threads: 6 x M3
Mounting Screw Centers: 25.2mm
Weight: 157g

Features:
• Sensor-based for excellent torque and smoothness even at slow speeds
• Adjustable timing for fine-tuning and CW or CCW rotation
• CNC machined T6 aluminum motor case for excellent heat dissipation
• High purity copper windings and 0.2mm ultra-thin silicon steel stator
• Powerful sintered neodymium magnets and high-speed oversize bearings
• Removable/replaceable Rotor
• Water and dustproof

Specs:
Type: Turnigy TrackStar 4268-2000KV High-Torque Sensored Brushless Motor
Scale: 1/8th
Poles: 4 (12 slots)
KV: 2000KV
Max RPM: 50,000
Sensored: Yes (Standard 6-pin lead)
Sensor Lead: Included
Max Voltage: 14.8V (4S)
Max Current: 97A
Resistance: 0.0099 ODM
Motor Diameter: 40.8mm
Motor Length: 68.7mm
Shaft Diameter: 5mm
Shaft Length: 19.5mm
Mounting Screw Threads: 4 x M3 or 4 x M4
Mounting Screw Centers: 25.2mm
Weight: 320g

Features:
• Sensor-based for excellent torque and smoothness even at slow speeds
• Adjustable timing for fine-tuning and CW or CCW rotation
• CNC machined T6 aluminum motor case for excellent heat dissipation
• High purity copper windings and 0.2mm ultra-thin silicon steel stator
• Powerful sintered neodymium magnets and high-speed oversize bearings
• Removable/replaceable Rotor
• Water and dustproof

Specs:
Type: Turnigy TrackStar 4268-2800KV High-Torque Sensored Brushless Motor
Scale: 1/8th
Poles: 4 (12 slots)
KV: 2800KV
Max RPM: 50,000
Sensored: Yes (Standard 6-pin lead)
Sensor Lead: Included
Max Voltage: 14.8V (4S)
Max Current: 130A
Resistance: 0.0056 ODM
Motor Diameter: 40.8mm
Motor Length: 68.7mm
Shaft Diameter: 5mm
Shaft Length: 19.5mm
Mounting Screw Threads: 4 x M3 or 4 x M4
Mounting Screw Centers: 25.2mm
Weight: 320g

Features:
• Sensor-based for excellent torque and smoothness even at slow speeds
• Adjustable timing for fine-tuning and CW or CCW rotation
• CNC machined T6 aluminum motor case for excellent heat dissipation
• High purity copper windings and 0.2mm ultra-thin silicon steel stator
• Powerful sintered neodymium magnets and high-speed oversize bearings
• Removable/replaceable Rotor
• Water and dustproof

Specs:
Type: Turnigy TrackStar 4268-1900KV High-Torque Sensored Brushless Motor
Scale: 1/8th
Poles: 4 (12 slots)
KV: 1900KV
Max RPM: 50,000
Sensored: Yes (Standard 6-pin lead)
Sensor Lead: Included
Input Voltage: 7.4~22.2V (2~6S)
Max Current: 90A
Resistance: 0.0114 ODM
Motor Diameter: 40.8mm
Motor Length: 68.7mm
Shaft Diameter: 5mm
Shaft Length: 19.5mm
Mounting Screw Threads: 4 x M3 or 4 x M4
Mounting Screw Centers: 25.2mm
Weight: 320g

Features:
• Sensor-based for excellent torque and smoothness even at slow speeds
• Adjustable timing for fine-tuning and CW or CCW rotation
• CNC machined T6 aluminum motor case for excellent heat dissipation
• High purity copper windings and 0.2mm ultra-thin silicon steel stator
• Powerful sintered neodymium magnets and high-speed oversize bearings
• Removable/replaceable Rotor
• Water and dustproof

Specs:
Type: Turnigy TrackStar 4268-2200KV High-Torque Sensored Brushless Motor
Scale: 1/8th
Poles: 4 (12 slots)
KV: 2200KV
Max RPM: 50,000
Sensored: Yes (Standard 6-pin lead)
Sensor Lead: Included
Input Voltage: 7.4~14.8V (2~4S)
Max Current: 112A
Resistance: 0.0085 ODM
Motor Diameter: 40.8mm
Motor Length: 68.7mm
Shaft Diameter: 5mm
Shaft Length: 19.5mm
Mounting Screw Threads: 4 x M3 or 4 x M4
Mounting Screw Centers: 25.2mm
Weight: 320g

Looking for an inexpensive motor replacement for your basher? These are just what the doctor ordered! These sensorless brushless motors are fitted with precision bearings, correctly rated magnets, balanced rotors, and premium grade steel shafts.

Looking for an inexpensive motor replacement for your basher? These are just what the doctor ordered! These sensorless brushless motors are fitted with precision bearings, correctly rated magnets, balanced rotors, and premium-grade steel shafts.

Looking for an inexpensive motor replacement for your basher? These are just what the doctor ordered! These sensorless brushless motors are fitted with precision bearings, correctly rated magnets, balanced rotors, and premium-grade steel shafts.

Looking for an inexpsensive motor replacement for your basher? These are just what the doctor ordered! These sensorless brushless motors are fitted with precision bearings, correctly rated magnets, balanced rotors, and premium grade steel shafts.

Looking for an inexpsensive motor replacement for your basher? These are just what the doctor ordered! These sensorless brushless motors are fitted with precision bearings, correctly rated magnets, balanced rotors, and premium grade steel shafts.

Tuned specifically for for use with 3.7v LiPo

The Turnigy TrackStar range of 1/10th Brushed Motors is ideal for those that require a no-nonsense motor that will power your vehicle in any conditions. These motors are an ideal solution for backyard bashers or anyone wanting to cross rivers or travel in a wet environment.

The Turnigy TrackStar range of 1/10th Brushed Motors is ideal for those that require a no-nonsense motor that will power your vehicle in any conditions. These motors are an ideal solution for backyard bashers or anyone wanting to cross rivers or travel in a wet environment.

The Turnigy TrackStar range of 1/10th Brushed Motors is ideal for those that require a no-nonsense motor that will power your vehicle in any conditions. These motors are an ideal solution for backyard bashers or anyone wanting to cross rivers or travel in a wet environment.

The Turnigy TrackStar range of 1/10th Brushed Motors is ideal for those that require a no-nonsense motor that will power your vehicle in any conditions. These motors are an ideal solution for backyard bashers or anyone wanting to cross rivers or travel in a wet environment.

The Turnigy TrackStar range of 1/10th Brushed Motors is ideal for those that require a no-nonsense motor that will power your vehicle in any conditions. These motors are an ideal solution for backyard bashers or anyone wanting to cross rivers or travel in a wet environment.

The Turnigy TrackStar range of 1/10th Brushed Motors is ideal for those that require a no-nonsense motor that will power your vehicle in any conditions. These motors are an ideal solution for backyard bashers or anyone wanting to cross rivers or travel in a wet environment.

将您的 1/18 RC 攀岩车从有刷电机升级到这款平稳、强劲的感应式无刷电机和电调组合。优质无刷电机采用独特的 0.2 毫米硅钢片定子和防爆磁性转子，最大功率可达 120 瓦。专门设计的电子调速器具有出色的启动、加速和线性功率特性，以及智能扭矩和速度闭环控制功能，可在所有负载下实现稳定的电机转速控制。

The Hobbywing EZRUN COMBO-MAX10 G2-80A ESC and 3652SD-5400KV G3 brushless motor offer strong, explosive power, linear low-speed control, and a great sense of control for your 1/10 RC car.

The Hobbywing EZRUN COMBO-MAX10 G2-80A ESC and 3652SD-3300KV G3 brushless motor offer strong, explosive power, linear low-speed control, and a great sense of control for your 1/10 RC car.

The Hobbywing EZRUN COMBO-MAX10 G2-80A ESC and 3652SD-4100KV G3 brushless motor offer strong, explosive power, linear low-speed control, and a great sense of control for your 1/10th RC car.

The Hobbywing QUICRUN Fusion PRO 2300KV 540 sensored brushless motor with integrated 60A brushless ESC greatly reduces the overall size and weight of the conventional separate setup. It has been designed specifically for 1/10 crawlers and offers strong low-speed torque, extremely smooth running at low speeds, and is far superior to the common sensored brushless system that has gone before. This compact combo also includes a powerful, adjustable SBEC system (6~7.4V@6A) which makes it suitable for HV servos.

The Hobbywing EZRUN series of brushless motors have become renowned for their dynamic, strong, output power, build quality, and excellent linearity at low speeds. This amazing linear low speed is achieved by a high-precision Hall sensor that ensures the rotor position is always accurate, and consistent for linear throttle response.

The Hobbywing EZRUN series of brushless motors have become renowned for their dynamic, strong, output power, build quality, and excellent linearity at low speeds. This amazing linear low speed is achieved by a high-precision Hall sensor that ensures the rotor position is always accurate, and consistent for linear throttle response.

The Hobbywing QUICRUN Fusion SE 1200KV 540 sensored brushless motor with integrated 40A brushless ESC greatly reduces the overall size and weight of the conventional separate setup. It has been designed specifically for 1/10 crawlers and offers strong low-speed torque, extremely smooth running at low speeds, and is far superior to the common sensored brushless system that has gone before. This compact combo also includes a powerful, adjustable SBEC system (6~7.4V@6A) which makes it suitable for HV servos.
